· Built-in Photos/videos recording functions and also support WIFI transmission
· 0.49 inch OLED 1440*1080 resolution display
· Alloy housing ,protection IP67,anti harsh environment
· Shock Resistance Up to 800g/ms ,and Impact resistance up to 6000J
· Standard 30 mm tube and Universal Mount Ring
Thermal Scope Model: JHRS7
|
Item |
RS735-384 |
RS750-384 |
RS735-640 |
RS750-640 |
|
|
Sensor |
Type |
Uncooled Vox FPA Micro bolometer |
|||
|
|
Pixel Array |
384×288 |
384×288 |
640×512 |
640×512 |
|
|
Pixel Pitch |
12μm |
|||
|
|
NETD |
≤35mk(25 °C, F#=1.0) |
|||
|
Image |
Focal Length |
35mm |
50mm |
35mm |
50mm |
|
|
FOV(±5%) |
7.5°*5.7° |
5.3°*4.0° |
12.6°*10.1° |
8.8°*7.0° |
|
|
Min Focus |
2m |
5m |
2m |
5m |
|
|
Lens Aperture |
F1.0 |
F1.0 |
F1.0 |
F1.0 |
|
|
Frame Rate |
50HZ |
|||
|
|
Focus method |
Manual |
|||
|
Display |
Display |
0.49 inch Color OLED 1440*1080 Resolution |
|||
|
|
Exit Pupil Diameter |
6mm |
|||
|
|
Exit Pupil distance |
65mm |
|||
|
|
Eyepieces Magnification |
11.2X |
|||
|
|
Basic Magnification |
X3.25 |
X4.65 |
X1.91 |
X2.72 |
|
|
Diopter |
Adjustable，-5D~+5D |
|||
|
|
Dimension |
351×84×76.2mm（W/ Eyeshade） |
368.2×84×77.2mm（ W/ Eyeshade) |
351×84×76.2mm（ W/ Eyeshade ) |
368.2×84×77.2mm（ W/ Eyeshade ） |
|
|
Weight |
≤932g |
≤1020g |
≤932g |
≤1020g |
|
Detection distance |
People （1.8×0.5）m |
1600m |
2300m |
1600m |
2300m |
|
|
Car（2.3×2.3）m |
2200m |
3200m |
2200m |
3200m |
|
Recognition Distance |
People （1.8×0.5）m |
800m |
1150m |
800m |
1150m |
|
|
Car（2.3×2.3）m |
1100m |
1600m |
1100m |
1600m |
